Technical Specifications
| Specification | Details |
|---|---|
| Brand | Dahua |
| Model | DH-HAC-B1A51-U-S2-0360B |
| Product Type | 5MP HDCVI IR Fixed-Focal Bullet Camera |
| Series | Dahua Cooper Series |
| Image Sensor | 5MP CMOS |
| Effective Pixels | 2880 × 1620 |
| Scanning System | Progressive Scan |
| Lens Type | Fixed-Focal Lens |
| Focal Length | 3.6mm |
| Lens Mount | M12 |
| Maximum Aperture | F2.0 |
| Field of View | Horizontal: 92° / Vertical: 48° / Diagonal: 109° |
| Minimum Illumination | 0.02 Lux @ F2.0, 30IRE; 0 Lux with IR |
| IR Illumination Distance | Up to 30m |
| IR Illumination | Smart IR |
| IR LEDs | 3 IR LEDs |
| Day & Night | ICR, Auto / Manual |
| Video Output | HDCVI / TVI / AHD / CVBS |
| Video Interface | 1 × BNC |
| Maximum Resolution | 5MP (2880 × 1620) |
| Frame Rate | 25fps @ 5MP |
| Supported Resolutions | 5MP / 4MP / 1080p / 960H |
| WDR | DWDR |
| Backlight Compensation | BLC / HLC |
| Noise Reduction | 2DNR |
| White Balance | Auto / Manual / Zone |
| Gain Control | Auto / Manual |
| Privacy Masking | Up to 8 Areas |
| Mirror | Supported |
| Angle Adjustment | Pan: 0°–360° / Tilt: 0°–90° / Rotation: 0°–360° |
| Power Supply | 12V DC ±30% |
| Power Consumption | ≤ 3.7W with IR On |
| Protection | IP67 |
| Housing Material | Metal |
| Operating Temperature | -40°C to +60°C |
| Operating Humidity | ≤95%, Non-Condensing |
| Dimensions | 146.1 × 70 × 69.8mm |
| Net Weight | Approx. 0.17kg |
