Technical Specifications
| Specification | Details |
|---|---|
| Brand | Dahua |
| Model | DH-HAC-HFW1239TLMP-A-LED-S2 |
| Product Type | Full-Color HDCVI Bullet Camera |
| Series | Dahua Lite Series |
| Image Sensor | 1/2.8-inch CMOS |
| Effective Pixels | 1920 × 1080 |
| Resolution | 2MP / 1080p |
| Scanning System | Progressive Scan |
| Minimum Illumination | 0.001 Lux @ F1.6, 30 IRE; 0 Lux with illumination |
| S/N Ratio | >65 dB |
| Illumination Type | LED / White Light |
| Illumination Distance | Up to 40m |
| Illumination Control | Auto / Manual |
| Lens Type | Fixed-Focal |
| Lens Mount | Built-in M12 |
| Focal Length | 3.6mm |
| Maximum Aperture | F1.6 |
| Horizontal Field of View | 86° |
| Vertical Field of View | 46° |
| Diagonal Field of View | 101° |
| Minimum Focus Distance | 1.1m |
| DORI Detection | 53.7m |
| DORI Observation | 21.5m |
| DORI Recognition | 10.7m |
| DORI Identification | 5.4m |
| Video Resolution | 1080p (1920 × 1080), 960H |
| Frame Rate | PAL: 25fps @ 1080p; NTSC: 30fps @ 1080p |
| Video Output | 1 × BNC, switchable HDCVI / TVI / AHD / CVBS |
| WDR | 130dB WDR |
| Backlight Compensation | BLC / HLC |
| Noise Reduction | 3D DNR |
| Super Adapt | Yes |
| White Balance | Auto / Area White Balance |
| Gain Control | Auto / Manual |
| Smart Illumination | Yes |
| Mirror | Off / On |
| Privacy Masking | Off / On, up to 8 areas |
| Audio | Built-in Microphone |
| Power Supply | 12V DC ±30% |
| Power Consumption | Maximum 5.1W with LED illumination on |
| Operating Temperature | -40°C to +60°C |
| Operating Humidity | Less than 95% RH, non-condensing |
| Protection | IP67 |
| Casing | Metal Front Cover + Plastic Main Body + Metal Bracket |
| Dimensions | 198.4 × 80.2 × 76.2mm |
| Net Weight | 0.28kg |
| Gross Weight | 0.43kg |
