Technical Specifications
| Specification | Details |
|---|---|
| Brand | Dahua |
| Model | DH-IPC-HFW1439TL1-A-IL-0360B |
| Product Type | 4MP Smart Dual Light Fixed-Focal Bullet Network Camera |
| Series | Dahua Entry Series |
| Image Sensor | 1/2.9-inch CMOS |
| Maximum Resolution | 2560 × 1440 (4MP) |
| Scanning System | Progressive Scan |
| Minimum Illumination | 0.006 Lux @ F1.6 (Color); 0.0006 Lux @ F1.6 (B/W); 0 Lux with illuminator |
| Lens Type | Fixed-Focal |
| Lens Mount | M12 |
| Focal Length | 3.6mm |
| Maximum Aperture | F1.6 |
| Horizontal Field of View | 78° |
| Vertical Field of View | 41° |
| Diagonal Field of View | 94° |
| Close Focus Distance | 1.7m |
| DORI – Detect | 85.4m |
| DORI – Observe | 34.2m |
| DORI – Recognize | 17.1m |
| DORI – Identify | 8.5m |
| IR Illumination Distance | Up to 30m |
| Warm Light Distance | Up to 30m |
| Illuminators | 2 × IR LED + 2 × Warm Light |
| Smart Dual Light | Supported |
| Day/Night | Auto ICR / Color / B&W |
| Video Compression | H.265 / H.264 / H.264H / H.264B / MJPEG |
| Smart Codec | Smart H.265+ / Smart H.264+ |
| Main Stream | 2560 × 1440 @ 1–25/30fps |
| Sub Stream | 704 × 576 @ 1–25fps / 704 × 480 @ 1–30fps |
| Stream Capability | 2 Streams |
| Bit Rate Control | CBR / VBR |
| Video Bit Rate | H.264: 32Kbps–4096Kbps; H.265: 12Kbps–4096Kbps |
| WDR | 120dB |
| Noise Reduction | 3D NR |
| Backlight Compensation | BLC / HLC |
| Motion Detection | 4 Areas |
| Region of Interest | 4 Areas |
| Human Detection | Supported |
| Vehicle Detection | Supported |
| Smart Illumination | Supported |
| Image Rotation | 0° / 180° |
| Privacy Masking | 4 Areas |
| Built-in Microphone | Yes |
| Audio Compression | G.711A / G.711Mu / PCM / G.726 |
| Network Interface | RJ-45 10/100 Base-T Ethernet |
| Network Protocols | IPv4 / IPv6 / HTTP / TCP / UDP / ARP / RTP / RTSP / RTCP / RTMP / SMTP / FTP / DHCP / DNS / DDNS / NTP / Multicast / ICMP / IGMP / P2P |
| Interoperability | ONVIF Profile S / Profile T / CGI |
| Maximum Users / Hosts | 6 Users / 24Mbps Total Bandwidth |
| Storage | FTP |
| Management Software | SmartPSS Lite / DSS / DMSS |
| Mobile Client | iOS / Android |
| Power Supply | 12V DC / PoE 802.3af |
| Basic Power Consumption | 2W DC / 2.9W PoE |
| Maximum Power Consumption | 6.4W DC / 7.7W PoE |
| Protection | IP67 |
| Operating Temperature | -40°C to +60°C |
| Operating Humidity | ≤95% RH |
| Housing Material | Metal + Plastic |
| Dimensions | 197.9 × 80.2 × 76.2mm |
| Net Weight | 0.31kg |
| Gross Weight | 0.45kg |
