Technical Specifications
| Specification | Details |
|---|---|
| Brand | Dahua |
| Model | DH-IPC-P5BP-PV-0360B (PICOOB15MP) |
| Product Type | 5MP Wi-Fi Pan & Tilt Network Camera |
| Series | Dahua Picoo B1 |
| Image Sensor | 1/2.7-inch CMOS |
| Effective Pixels | 2880 × 1620 |
| Resolution | 5MP |
| Lens Type | Fixed-Focal |
| Focal Length | 3.6mm |
| Maximum Aperture | F1.6 |
| Horizontal Field of View | 78° |
| Vertical Field of View | 40° |
| Diagonal Field of View | 93° |
| Pan Range | 0°–355° |
| Tilt Range | 0°–90° |
| IR Illumination Distance | Up to 30m |
| Warm Light Distance | Up to 30m |
| Illuminators | 2 × IR LED + 2 × Warm Light |
| Smart Dual Light | Supported |
| Day/Night | Auto ICR / Color / B&W |
| Video Compression | H.265 |
| Main Stream | 2880 × 1620 @ 1–25/30fps |
| Sub Stream | 640 × 360 @ 1–25/30fps |
| Video Bit Rate | 80Kbps–4096Kbps |
| WDR | DWDR |
| Motion Detection | Supported |
| Human Detection | Supported |
| Vehicle Detection | Supported |
| SMD | SMD 3.0 |
| Intelligent Tracking | Supported |
| Sound & Light Alarm | Supported |
| Built-in Microphone | Yes |
| Built-in Speaker | Yes |
| Two-Way Talk | Supported |
| Audio Compression | G.711A |
| Network Port | RJ-45 10/100 Base-T |
| Wi-Fi Standard | IEEE 802.11b/g/n/ax |
| Wi-Fi Frequency | 2.412GHz–2.472GHz, 2.4GHz |
| Storage | MicroSD up to 256GB |
| Management Software | DMSS |
| Mobile Client | iOS / Android |
| Power Supply | 12V DC, 1A |
| Basic Power Consumption | 1.68W |
| Maximum Power Consumption | 4.56W |
| Protection | IP65 |
| Operating Temperature | -20°C to +50°C |
| Operating Humidity | ≤95% |
| Housing Material | Plastic |
| Dimensions | 116 × 138 × 139mm |
| Net Weight | 425g |
