Technical Specifications
| Specification | Details |
|---|---|
| Brand | Dahua |
| Model | DHI-NVR4216-16P-4KS3 |
| Series | NVR4-4KS3 Series |
| Product Type | PoE Network Video Recorder |
| IP Camera Channels | 16 Channels |
| PoE Ports | 16 × PoE Ports |
| PoE Standard | IEEE 802.3af / 802.3at |
| PoE Port Speed | 10/100 Mbps |
| Total PoE Power | 130W |
| Maximum Power Per PoE Port | 25.5W |
| Maximum Camera Resolution | Up to 12MP |
| Incoming Bandwidth | 160 Mbps |
| Recording Bandwidth | 160 Mbps |
| Outgoing Bandwidth | 80 Mbps |
| Video Compression | Smart H.265+ / H.265 / Smart H.264+ / H.264 |
| Maximum Decoding | 8 × 1080P @ 30fps / 2 × 8MP @ 30fps |
| HDMI Output | 1 × HDMI, up to 4K |
| VGA Output | 1 × VGA |
| HDD Bays | 2 × SATA |
| Maximum HDD Capacity | Up to 20TB per HDD |
| Total Maximum Storage | Up to 40TB with 2 × 20TB HDDs |
| Network Interface | 1 × RJ45 Gigabit Ethernet |
| Network Speed | 10/100/1000 Mbps |
| Audio Input | 1 × RCA |
| Audio Output | 1 × RCA |
| Alarm Inputs | 4 Channels |
| Alarm Outputs | 2 Channels |
| USB Ports | 2 × USB 2.0 |
| RS-232 | 1 × RS-232 |
| AI by Recorder | 4-Channel SMD Plus |
| AI by Camera | Face Detection, Face Recognition, Perimeter Protection, SMD, People Counting, Stereo Analysis, Heat Map |
| Perimeter Protection | Up to 6 Camera Channels |
| Face Detection | Supported through compatible cameras |
| Face Recognition | Supported through compatible cameras |
| SMD Plus | 4 Channels by NVR |
| ONVIF | Profile T / S / G |
| Recording Modes | General / Motion Detection / Intelligent / Alarm |
| Playback | Up to 16 Channels |
| Backup | USB Device / Network |
| Mobile Access | Android / iOS |
| Operating System | Embedded Linux |
| Power Supply | 100–240V AC, 50/60Hz |
| NVR Power Consumption | <10W without HDD |
| Installation | Rack / Desktop |
| Rack Size | 1U |
| Dimensions | 375 × 327.9 × 53mm |
| Net Weight | 2.60kg |
| Operating Temperature | -10°C to +55°C |
| Operating Humidity | 10%–93% RH, non-condensing |
