Technical Specifications
| Specification | Details |
|---|---|
| Brand | Dahua |
| Model | DH-XVR5104HS-4KL-I3 |
| Product Type | 4-Channel Penta-brid 4K/5MP WizSense XVR Digital Video Recorder |
| Analog Video Input | 4 × BNC |
| Video Standards | HDCVI / AHD / TVI / CVBS Auto-detect |
| IP Camera Input | Up to 8 Channels |
| Maximum IP Camera Resolution | Up to 8MP per channel |
| Incoming Bandwidth | 64 Mbps |
| Recording Resolution | 4K-N / 5MP / 4MP / 3MP / 1080P / 1080N / 720P / 960H / D1 / CIF |
| Video Compression | AI Coding / H.265+ / H.265 / H.264+ / H.264 |
| Dual Stream | Yes |
| SMD Plus | 4 Channels by Recorder / 8 Channels by Camera |
| Human & Vehicle Detection | Yes |
| Perimeter Protection | Up to 4 Channels |
| IVS Rules | Tripwire / Intrusion Detection |
| Face Detection | 1 Channel, up to 8 face images/s |
| Face Recognition | 1 Channel |
| Face Database | Up to 10 databases and 20,000 face images |
| QuickPick 2.0 | 2 Channels |
| AI Coding | 4 Channels |
| Audio Input | 4-Channel BNC Coaxial Audio |
| Audio Output | 1 × RCA |
| Two-Way Talk | Yes, using the first audio input |
| HDD Interface | 1 × SATA |
| Maximum HDD Capacity | Up to 16TB |
| USB | 2 × USB 2.0 |
| HDMI Output | 1 × HDMI |
| VGA Output | 1 × VGA |
| Network Port | 1 × RJ-45 10/100 Mbps Ethernet |
| RS-485 | 1 Port for PTZ Control |
| Mobile Access | iOS / Android |
| ONVIF | Supported |
| POS Function | Yes |
| IoT Function | Yes |
| Power Supply | 12V DC, 2A |
| Power Consumption | Less than 7W |
| Operating Temperature | -10°C to +55°C |
| Operating Humidity | 0%–90% RH |
| Installation | Desktop / Rack |
| Dimensions | 260.0 × 237.9 × 47.6mm |
| Net Weight | 0.96kg |
| Gross Weight | 1.37kg |
| Certifications | CE / FCC |
