Technical Specifications
| Specification | Details |
|---|---|
| Brand | Dahua |
| Model | DHI-XVR5108HS-I3 |
| Product Type | 8-Channel Penta-brid WizSense XVR Digital Video Recorder |
| Series | Dahua WizSense XVR5000-I3 Series |
| Analog Video Channels | 8 Channels |
| Analog Video Input | HDCVI / AHD / TVI / CVBS, Auto-detect |
| IP Camera Channels | Up to 12 Channels |
| Maximum IP Camera Resolution | Up to 6MP |
| Total Incoming Bandwidth | 64 Mbps |
| Recording Resolution | 5M-N, 4M-N, 1080p, 1080N, 720p, 960H, D1, CIF |
| 5MP Recording | Up to 10fps per channel |
| 1080p Recording | Up to 15fps per channel |
| Sub-stream Resolution | D1 / CIF |
| Video Compression | AI Coding / Smart H.265+ / H.265 / Smart H.264+ / H.264 |
| Audio Compression | G.711a / G.711u / PCM |
| SMD Plus | 8 Channels by Recorder |
| Human & Vehicle Detection | Yes |
| Perimeter Protection | Up to 1 Channel |
| IVS Rules | Tripwire / Intrusion Detection |
| Face Detection | 1 Channel |
| Face Recognition | 1 Channel |
| AI Coding | Yes |
| Intelligent Search | Yes |
| Audio Input | 1 × RCA + 8 × BNC Coaxial Audio |
| Audio Output | 1 × RCA |
| Two-Way Talk | Yes |
| HDD Interface | 1 × SATA |
| Maximum HDD Capacity | Up to 16TB |
| USB | 2 × USB 2.0 |
| HDMI Output | 1 × HDMI |
| VGA Output | 1 × VGA |
| Network Port | 1 × RJ-45 10/100 Mbps Ethernet |
| RS-485 | 1 Port, PTZ Control |
| Network Protocols | HTTP / HTTPS / TCP/IP / IPv4 / IPv6 / RTSP / UDP / NTP / DHCP / DNS / SMTP / UPnP / FTP / DDNS / P2P |
| Mobile Access | iOS / Android |
| ONVIF | Supported |
| Backup | USB Device / Network |
| POS Function | Yes |
| IoT Function | Yes |
| Power Supply | 12V DC, 2A |
| Power Consumption | Less than 7W without HDD |
| Operating Temperature | -10°C to +55°C |
| Operating Humidity | 10%–90% RH, non-condensing |
| Installation | Desktop |
| Dimensions | 260.0 × 237.8 × 47.6mm |
| Net Weight | 0.97kg |
| Gross Weight | 1.39kg |
