| Specification |
Details |
| Brand |
Hikvision |
| Model |
DS-7608NI-Q1(D) |
| Product Type |
8-Channel 4K Network Video Recorder (NVR) |
| IP Camera Input |
8 Channels |
| Incoming Bandwidth |
80 Mbps |
| Outgoing Bandwidth |
80 Mbps |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Recording Resolution |
8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Decoding Capability |
1-Channel @ 8MP (30fps) / 3-Channel @ 4MP (30fps) / 6-Channel @ 1080p (30fps) |
| Synchronous Playback |
8 Channels |
| Stream Type |
Video / Video & Audio |
| Audio Compression |
G.711 μ-law / G.711 A-law / G.722 / G.726 |
| HDMI Output |
1 Channel, up to 4K resolution |
| HDMI Resolution |
4096 × 2160 @ 30Hz / 3840 × 2160 @ 30Hz / 2560 × 1440 @ 60Hz / 1920 × 1080 @ 60Hz / 1600 × 1200 @ 60Hz / 1280 × 1024 @ 60Hz / 1280 × 720 @ 60Hz |
| VGA Output |
1 Channel, up to 1920 × 1080 @ 60Hz |
| Video Output Mode |
HDMI / VGA Simultaneous Output |
| Audio Output |
1 × RCA, Linear, 1KΩ |
| Two-Way Audio |
1 × RCA, 2.0 Vp-p, 1KΩ |
| Motion Detection |
Motion Detection 2.0, 4 Channels |
| Human / Vehicle Analysis |
4 Channels |
| Smart Functions |
VCA Events, Motion Detection, Line Crossing, Intrusion Detection and Smart Search |
| Remote Connections |
Up to 32 Remote Connections |
| Network Interface |
1 × RJ45 10/100 Mbps Self-Adaptive Ethernet |
| Network Protocols |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Hik-Connect |
Supported |
| SATA Interface |
1 × SATA Interface |
| HDD Capacity |
Up to 8TB per HDD |
| USB Interface |
2 × USB 2.0 |
| Alarm Input / Output |
N/A (4/1 Optional) |
| Power Supply |
12V DC, 1.5A |
| Power Consumption |
≤ 10W Without HDD |
| Operating Temperature |
-10°C to 55°C |
| Operating Humidity |
10% to 90% |
| Dimensions |
320 × 240 × 48 mm |
| Weight |
≤ 1 kg, Without HDD |
