| Specification |
Details |
| Brand |
Hikvision |
| Model |
DS-7616NXI-K2(D) |
| Product Type |
16-Channel AcuSense 4K Network Video Recorder (NVR) |
| Series |
Hikvision K Series AcuSense NVR |
| Chassis |
1U |
| IP Camera Inputs |
16 Channels |
| Incoming Bandwidth |
160 Mbps |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Maximum Recording Resolution |
Up to 12MP |
| Supported Recording Resolutions |
12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Decoding Capability |
Up to 2-Channel @ 12MP / 3-Channel @ 8MP / 6-Channel @ 4MP / 12-Channel @ 1080p |
| Synchronous Playback |
16 Channels |
| Stream Type |
Video / Video & Audio |
| HDMI Output |
1 × HDMI, up to 4K resolution |
| VGA Output |
1 × VGA |
| Video Output Mode |
HDMI / VGA Simultaneous Output |
| Motion Detection |
Motion Detection 2.0 on All Channels |
| Human & Vehicle Detection |
Human and Vehicle Recognition to Reduce False Alarms |
| AcuSense Technology |
Supported |
| Facial Recognition |
Supported for Video Stream and Face Picture Recognition |
| Smart Search |
Smart Search and Smart Playback |
| Perimeter Protection |
Supported |
| Network Interface |
1 × RJ45 10/100/1000 Mbps Self-Adaptive Ethernet |
| Network Protocols |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Hik-Connect |
Supported |
| SATA Interface |
2 × SATA Interfaces |
| HDD Capacity |
Up to 16TB per HDD |
| HDD Bays |
2 × HDD Bays |
| USB Interface |
USB Interfaces for External Devices |
| Audio Input |
1 × RCA |
| Audio Output |
1 × RCA |
| Two-Way Audio |
Supported |
| Alarm Input / Output |
Alarm Input and Alarm Output Interfaces |
| Video Output |
HDMI and VGA |
| Power Supply |
12V DC |
| Operating Temperature |
-10°C to 55°C |
| Dimensions |
385 × 315 × 52 mm |
