| Specification |
Details |
| Brand |
Hikvision |
| Model |
iDS-7216HQHI-M2/XT |
| Product Type |
16-Channel AcuSense H.265 DVR |
| Series |
Hikvision AcuSense PRO Series |
| Chassis |
1U |
| Analog Video Inputs |
16 Channels, BNC |
| Supported Video Signals |
HDTVI / AHD / HDCVI / CVBS / IP |
| IP Camera Inputs |
8 Channels Standard, Expandable up to 24 Channels |
| Maximum IP Camera Resolution |
Up to 6MP per Channel |
| Maximum IP Camera Capacity |
Up to 24 IP Cameras |
| HDTVI Resolution |
Up to 3K / 5MP Lite depending on recording mode |
| Recording Resolution |
3K Lite / 5MP Lite / 4MP Lite / 1080p / 720p / VGA / WD1 / 4CIF / CIF |
| Maximum Encoding Capability |
Up to 3K / 5MP Lite @ 12fps |
| Video Compression |
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
| Video Bitrate |
32 Kbps to 6 Mbps |
| Dual Stream |
Supported |
| Decoding Capability |
Up to 24 Channels 1080p @ 30fps |
| Synchronous Playback |
16 Channels |
| Audio Input |
1 × RCA; Audio Over Coaxial on HDTVI Channels |
| Audio Output |
1 × RCA, Linear, 1KΩ |
| Two-Way Audio |
Supported |
| Audio Compression |
G.711u |
| Audio Bitrate |
64 Kbps |
| Facial Recognition |
Up to 4 Channels |
| Face Picture Libraries |
Up to 16 Face Picture Libraries |
| Face Picture Comparison |
Up to 4-Channel Face Picture Comparison Alarm |
| Facial Detection |
Face Picture Detection, Capture and Search; Up to 4 Channels |
| Motion Detection 2.0 |
Up to 16 Analog Channels with Deep Learning Human / Vehicle Classification |
| Perimeter Protection |
Up to 8 Channels on Advanced Model |
| Perimeter Detection |
Line Crossing / Intrusion Detection with Human and Vehicle Classification |
| AcuSearch |
Up to 8 Channels |
| Smart Playback |
Supported |
| HDMI Output |
1 Channel, Up to 4K (3840 × 2160) @ 30Hz |
| VGA Output |
1 Channel, Up to 1920 × 1080 @ 60Hz |
| CVBS Output |
1 Channel BNC |
| HDMI / VGA |
Simultaneous Output Supported |
| Network Interface |
1 × RJ45 10/100/1000 Mbps Self-Adaptive Ethernet |
| Network Bandwidth |
256 Mbps Total Bandwidth |
| Remote Connections |
Up to 128 Remote Connections |
| Network Protocols |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP |
| Hik-Connect |
Supported |
| HDD Interface |
2 × SATA |
| Maximum HDD Capacity |
Up to 12TB per HDD, depending on supported configuration |
| USB Interfaces |
Front: 1 × USB 2.0; Rear: 2 × USB 3.0 |
| Serial Interface |
RS-485, Half-Duplex |
| Alarm Interface |
Variant dependent |
| Power Supply |
12V DC, 3.3A |
| Power Consumption |
Maximum 40W |
| Operating Temperature |
-10°C to 55°C |
| Operating Humidity |
10% to 90% |
| Dimensions |
Approx. 384 × 317 × 52mm |
| Weight |
≤ 2kg, Without HDD |
